Automatic Double Head Augur Powder Filling Machine Model HHZ-FJ-200 is suitable for Filling Dry Syrup, Powder and Granules in different type and shape of bottles with maximum speed up to 30 Bottles per minute depending on Fill Volume, type of Powder and Bottle Size using Single track twin hopper system. Machine with proven Augur type Powder Filling System for filling higher gram mage of Powder in Single Dose. The main body of the machine with 304 stainless steel manufacturing, motor, cylinder, electrical accessories, pneumatic components are selected well-known brand,all Parts coming in contact with powder are made from SS316, Nylon and HDPE material. Machine with no change parts system for change in Size of Bottles due to pneumatically operated bottle separator system. Machine with built in Turn Table for Round Bottle at the infeed for continuous feeding of bottles.The packing weight can be adjusted steplessly at any time, and the working state can be changed at any time. Can Store 10 sets of formula parameters.
1. Filling with weighing and reject, which can improve the accuracy of filling weight and is suitable for high-value products;
2. full automatic solution, to realize feeding, weighing, filling, servo capping, foil sealing, and labeling;
3. Servo capping machine, adjustable torque, can be screwed tighter.
Workflow:
Auto-feeding empty bottles
Vacuum Feeding Machine
2 Heads Powder Filling Machine
Automatic Weight Checker and Reject Function
Automatic Cap Feeder
Servo Capping Machine
Automatic Aluminum Foil Sealing Machine
Labeling Machine
Collecting Table
| Model | HHZ-FJ-200 |
| Adaptation Specification | 100-1000g adjustable (shift screw attachment) |
| Filling speed | 20-30Cans/min (depending on material and filling capacity) |
| Metering error | ±0.5% |
| Power | 380v 50Hz |
| Power | 5kw |
| Contour dimension | 2000*1100*2100mm |
| Weight | 900kg |
